Introduction:

Potable induction heating device is widely applied in industries such as refrigeration and HVAC, household appliances, automobile manufacturing, and medical devices.

It is especially suitable for brazing processes, such as air conditioning refrigeration valve components, refrigerator/freezer tubing components, solar energy fittings, compressor parts, washing machines (pipe-to-pipe connections, pipe-to-shell connections, pipe-to-valve connections), automobile evaporators, compressor connections, short-circuit rings on motors, and other brazing processes.

Advantage:

1. Convenient Mobility: Handheld brazing equipment enables induction brazing for complex and hard-to-reach workpieces or workshop positions with small size, easy mobility, and simple operation.

2. Good Controllability: The precise control of induction heating minimizes the risk of overheating during heating, avoiding damage to heated components and increase product qualification

3. Precise Operation: Stable and vibration-free heating ensures accurate welding positions. It can weld metals with a minimum diameter of 0.1mm and the inductors can be customized according to the different shapes of workpieces.

4. Convenient Operation: Induction heating can be processed at the places that store heating workpieces, just moving heating head for brazing or other process.

5. Cost Reduction: Efficient and precise heating processes by induction ensure the qualification rate of welding, minimizing waste, rework, and energy consumption.

6. Comfortable Working Environment: Induction heating is quiet and without causing a rise in the surrounding environment’s temperature.

Induction brazing

Induction hardening

Induction annealing

Induction heating

Name Hand-held Digital Induction Heating Equipment
Control method All digital circuit mode
Working mode Manual mode, automatic mode, temperature control mode (optional)
Number of
heating current settings
5-stage
The number of stored workpiece parameters 10pcs/mode
Content of working status Time, current, temperature (optional)
Alarm interface Overcurrent,overpressure,under water,undervoltage,phase loss,overheat,etc.
Model PHC-S-30 PHC-S-35 PHC-S-40 PHC-S-50 PHC-S-60 PHC-S-80
Output power 3-30KVA    3-35KVA    3-40KVA    3-50KVA   3-60KVA   3-80KVA
Output frequency range 10~60KHz  10~20KHz  10~60KHz  10~35KHz  10~20KHz  10~20KHz
Length of main extension cable 2-5m 2-5m 2-5m 2-5m 2-5m 2-5m
Input voltage 380V±10%  380V±10%  380V±10%  380V±10%  380V±10%  380V±10%
Input frequency 50/60Hz  50/60Hz  50/60Hz  50/60Hz  50/60Hz  50/60Hz
Min circuit breaker 3P-63A  3P-63A  3P-63A  3P-80A  3P-125A  3P-125A
Max inlet water temperature 35℃  35℃  35℃  35℃  35℃  35℃
Water pressure(Max/min) 4/6bar 4/6bar 4/6bar 4/6bar 4/6bar 4/6bar
Working environment temperature  +5℃~+35℃  +5℃~+35℃  +5℃~+35℃  +5℃~+35℃  +5℃~+35℃  +5℃~+35℃
Dimensions(L*W*H) 600×400×620mm   600×400×620mm    600×400×620mm

1. How to choose the portable induction heating machine?

 Please tell us with the dimensions and heating area of workpiece, heating temperature and heating time, as well as any specific requirement of heating       process, our experience sales will recommend the appropriate induction heating equipment.

2. Can we see the heating test before purchase induction heater?

 Customs can send the workpiece to us for heating testing in our laboratory, and decide whether purchase HCGP induction machine after received the         heating testing video and report.

3. How about the service of installation and commission?

The details manual and guide for installation and commission with picture and video will be sent to our customers. Most of our customers can complete installation and commission on their own follow our instructions. We still provide paid on-site installation service.

4. The operation manual provides work standards for regular maintenance and guidance for dealing common fault. we also help you manage your spare parts inventory.

5. How can customer get service when the machine get problem?

We provide 7x24h online technical support and repair service as well as on-site service.

6. Can you provide repair parts for a long time?

Yes, we will help our customer manage their spare parts inventory.

7. Can you help us design coil for our new produces?

We offer different induction coil service:

  • Induction Coil design with pre-purchase heating testing
  • Induction Coil design for different heating workpieces when purchasing induction equipment
  • Induction Coil design for customers when they developing new products
  • Guide customers to make induction coils on their own
